Product Name：Cable Entry System
Product Code：CF 32
Inquiry
General
Variants
Sets
CF 32 Cable Entry System
Temperature
-40-120℃
Protection grade
IP54
Description
CF 32 is suitable for cable/pipe penetration sealing in compact parts of the cabinet. The frame is a cast aluminum frame with an integrated pressing device. CF 32 can seal up to 56 cables
Application
Cabinet, control cabinet, power cabinet, etc
Model
Number of modules used
DMK15×40
DMK20×40
DMK40
CF32/8
/
/
8
CF32/11
/
2
7
CF32/14
/
4
6
CF32/17
/
6
5
CF32/20
/
8
4
CF32/28
8
/
5
CF32/32
/
16
/
CF32/41
8
8
1
CF32/50
16
/
2
CF32/56
16
2
/
